Amxon-VERTICAL SAFETY LASER SENSOR
CNB-220L
Detection principle: TOF light time-of-flight difference
Light medium: 890nm infrared laser
Laser class: Class I eye-safe laser
Detection response time: Normal mode 20ms, ultra-stable mode 100ms
Detection range: Minimum 20cm from the ground
Detection angle: Recessed ±4° adjustable
Maximum installation height: 5m (fixed position), 3.5m (moving door leaf)
Operating temperature: -20℃~60℃
Operating voltage: AC/DC12~30V
Operating current: Standby 50mA, active 90mA (at 12V power supply)
Signal output: Relay normally open or normally closed
Function indicator: LED, blue in standby, red when an object is detected
