Amxon- Integrated Safety Beam Sensor
CNB-601
• Detection Method: Through-beam (opposed type)
• Detectable Object: Opaque objects ≥ 2 cm
• Through-Beam Distance: 10 m
• Operating Voltage: 10–24 VDC
• Transmitter Operating Current: 12.6 mA
• Receiver Operating Current: 1.85 mA
• Response Time: 30 ms
• Infrared Light Source: 940 nm
• Operating Mode: Interruption output
• Output Control: NPN open-collector
• Maximum Load Capacity: DC 24 V, 100 mA
• Operating Humidity: 10%–90% RH
• Operating Temperature: 20°C to 45°C
• Cable Specification:
• Transmitter: 2-core cable
• Receiver: 3-core cable
• Cable length: 5.5 m
