Amxon - Mini Microwave Motion Infrared Presence Sensor
CNB-530/530D
• Input Power Supply: AC/DC 12–30 V (±10%)
• Cable Length: 2.5 m
• Output Contact: Normally Open (NO)
• Maximum Installation Height: 3000 mm
• Operating Current:
• Standby: 27 mA
• Active: 47 mA
• Product Dimensions: 116 (L) × 49 (W) × 34 (H) mm
• Housing Material: ABS
• Light Type: Modulated infrared light
• Light Source: 940 nm infrared
• Beam Configuration: 3 channels, 12 transmitters, 48 light points
• Power-on Self-Learning Time: Dynamic learning, stabilizes within 2 seconds
• Operating Temperature Range: -40°C to +60°C (non-condensing)
• Detection Area: 1800 (W) × 1500 (D) mm
• Output Hold Time: 500 ms
• Response Time: ≤ 100 ms
• Optical Surface: PMMA
