Amxon - Laser Safety Curtain Sensor
CNB-227L
• Detection Principle: TOF (Time of Flight)
• Light Source: 890 nm infrared laser
• Laser Class: Class I eye-safe laser
• Detection Area Diameter: 100 mm spot (when installed at 2.8 m height)
• Detection Response Time: ≤ 50 ms
• Detection Range: Minimum 20 cm above ground
• Detection Angle: Adjustable 0–25°
• Maximum Installation Height:
• 5 m (fixed position)
• 3.5 m (moving door leaf)
• Operating Temperature: -20°C to +60°C
• Operating Voltage: AC/DC 12–30 V
• Standby Current: 50 mA (at 12 V supply)
• Active Current: 90 mA (at 12 V supply)
• Signal Output: Relay output, Normally Open (NO) or Normally Closed (NC)
• Trigger Mode: Motion and stationary detection
• Status Indicator: LED indicator
• Blue in standby mode
• Red when an object is detected
• Housing Material: Aluminum alloy, ABS, PC
• Sensor Dimensions: 310 × 31 × 20 mm, 620 × 31 × 20 mm, 750 × 31 × 20 mm, 900 × 31 × 20 mm, 1200 × 31 × 20 mm (optional）
