Panic Bolt

WIESS Stainless Steel Touch Bar Panic Device

CMP350 Series

Key Specs

• Construction: Stainless steel
• Finish: Satin stainless steel
• Handing: Handed (except where noted)
• Compliance: Tested for durability, fire/smoke door suitability, safety, corrosion resistance, and security

Available Models

CMP351

• 1-point locking
• Standard application
• Compatible with CMPA012 / 112 / 212 trims

CMP355

• 1-point locking
• Works with mortise lock (CC 72/85/92 mm)
• No trim included

CMP356

• 2-point locking
• Standard application
• Compatible with CMPA012 / 112 / 212 trims

Door Width Compatibility

• Standard: Push bar 850 mm (CMP350P/S = 960 mm; CMP350L = 980 mm)
• Extended: Up to 1200 mm (push bar 1100 mm)

Door Height Compatibility

• Standard Rods: 84" (2134 mm)
• Extension Rods: 96" (2438 mm)
• Special Rods: 120" (3048 mm)

Additional Specifications

• Door Thickness: 1¾" to 2¼" (44–57 mm) – compatible with wood or metal doors
• Trim Lock Cylinder: Square shape
• Dogging: Not available for fire-rated applications
